Table of Contents
1.Introduction
1.1 History of the Airbreathing Jet Engine, a Twentieth-Century InventionâThe Beginning
1.2 Innovations in Aircraft Gas Turbine Engines
1.3 New Engine Concepts
1.4 New Vehicles
1.5 Summary
1.6 Roadmap for the Second Edition
References
Problems
2. Compressible Flow with Friction and Heat: A Review
2.1 Introduction
2.2 A Brief Review of Thermodynamics
2.3 Isentropic Process and Isentropic Flow
2.4 Conservation Principles for Systems and Control Volumes
2.5 Speed of Sound & Mach Number
2.6 Stagnation State
2.7 Quasi-One-Dimensional Flow
2.8 AreaâMach Number Relationship
2.9 Sonic Throat
2.10 Waves in Supersonic Flow
2.11 Normal Shocks
2.12 Oblique Shocks
2.13 Conical Shocks
2.14 Expansion Waves
2.15 Frictionless, Constant-Area Duct Flow with Heat Transfer
2.16 Adiabatic Flow of a Calorically Perfect Gas in a Constant-Area Duct with Friction
2.17 Friction (Drag) Coefficient Cf and DâArcy Friction Factor fD
2.18 Dimensionless Parameters
2.19 Fluid Impulse
2.20 Summary of Fluid Impulse
References
Problems 103
3. Engine Thrust and Performance Parameters
3.1 Introduction
3.2 Installed ThrustâSome Bookkeeping Issues on Thrust and Drag
3.3 Engine Thrust Based on the Sum of Component Impulse
3.4 Rocket Thrust
3.5 Airbreathing Engine Performance Parameters
3.6 Modern Engines, Their Architecture and Some Performance Characteristics
3.7 Summary
References
Problems
4. Gas Turbine Engine Cycle Analysis
4.1 Introduction
4.2 The Gas Generator
4.3 Aircraft Gas Turbine Engines
4.4 Analysis of a Mixed-Exhaust Turbofan Engine with an Afterburner
4.5 The Turboprop Engine
4.6 Summary
References
Problems
5. General Aviation and Uninhabited Aerial Vehicle Propulsion System
5.1 Introduction
5.2 Cycle Analysis
5.3 Power and Efficiency
5.4 Engine Components and Classifications
5.5 Scaling of Aircraft Reciprocating Engines
5.6 Aircraft Engine Systems
5.7 Electric Engines
5.8 Propellers and Reduction Gears
References
Problems
6. Aircraft Engine Inlets and Nozzles
6.1 Introduction
6.2 The Flight Mach Number and Its Impact on Inlet Duct Geometry
6.3 Diffusers
6.4 An Ideal Diffuser
6.5 Real Diffusers and Their Stall Characteristics
6.6 Subsonic Diffuser Performance
6.7 Subsonic Cruise Inlet
6.8 Transition Ducts
6.9 An Interim Summary for Subsonic Inlets
6.10 Supersonic Inlets
6.11 Normal Shock Inlets
6.12 External Compression Inlets
6.13 Variable GeometryâExternal Compression Inlets
6.14 Mixed-Compression Inlets
6.15 Supersonic Inlet Types and Their PerformanceâA Review
6.16 Standards for Supersonic Inlet Recovery
6.17 Exhaust Nozzle
6.18 Gross Thrust
6.19 Nozzle Adiabatic Efficiency
6.20 Nozzle Total Pressure Ratio
6.21 Nozzle Pressure Ratio (NPR) and Critical Nozzle Pressure Ratio (NPRcrit.)
6.22 Relation Between Nozzle Figures of Merit, n and n
6.23 A Convergent Nozzle or a De Laval?
6.24 The Effect of Boundary Layer Formation on Nozzle Internal Performance
6.25 Nozzle Exit Flow Velocity Coefficient
6.26 Effect of Flow Angularity on Gross Thrust
6.27 Nozzle Gross Thrust Coefficient Cfg
6.28 Overexpanded Nozzle FlowâShock Losses
6.29 Nozzle Area Scheduling, A8 and A9/A8
6.30 Nozzle Exit Area Scheduling, A9/A8
6.31 Nozzle Cooling
6.32 Thrust Reverser and Thrust Vectoring
6.33 Hypersonic Nozzle
6.34 Exhaust Mixer and Gross Thrust Gain in a Mixed-Flow Turbofan Engine
6.35 Noise
6.36 Nozzle-Turbine (Structural) Integration
6.37 Summary of Exhaust Systems
References
Problems
7. Combustion Chambers and Afterburners
7.1 Introduction
7.2 Laws Governing Mixture of Gases
7.3 Chemical Reaction and Flame Temperature
7.4 Chemical Equilibrium and Chemical Composition
7.5 Chemical Kinetics
7.6 Combustion Chamber
7.7 Combustion-Generated Pollutants
7.8 Aviation Fuels
7.9 Alternative âDrop-Inâ Jet Fuels (AJFs)
7.10 Combustion Instability: Screech and Rumble
7.11 Summary
References
Problems 518
8. Axial Compressor Aerodynamics
8.1 Introduction
8.2 The Geometry
8.3 Rotor and Stator Frames of Reference
8.4 The Euler Turbine Equation
8.5 Axial-Flow Versus Radial-Flow Machines
8.6 Axial-Flow Compressors and Fans
8.7 Compressor Performance Map
8.8 Compressor Instability â Stall and Surge
8.9 Multistage Compressors and Their Operating Line
8.10 Multistage Compressor Stalling Pressure Rise and Stall Margin
8.11 Multistage Compressor Starting Problem
8.12 The Effect of Inlet Flow Condition on Compressor Performance
8.13 Isometric and Cutaway Views of Axial-Flow Compressor Hardware
8.14 Compressor Design Parameters and Principles
8.15 Summary
References
Problems
9. Centrifugal Compressor Aerodynamics
9.1 Introduction
9.2 Centrifugal Compressors
9.3 Radial Diffuser
9.4 Inducer
9.5 Inlet Guide Vanes (IGVs) and Inducer-Less Impellers
9.6 Impeller Exit Flow and Blockage Effects
9.7 Efficiency and Performance
9.8 Summary
References
Problems
10. Aerothermo-dynamics of Gas Turbines
10.1 Introduction
10.2 Axial-Flow Turbines
10.3 Turbine Performance Map
10.4 The Effect of Cooling on Turbine Efficiency
10.5 Turbine Blade Profile Design
10.6 Stresses in Turbine Blades and Disks and Useful Life Estimation
10.7 Axial-Flow Turbine Design and Practices
10.8 Gas Turbine Design Summary
10.9 Summary
References
Problems
11. Aircraft Engine Component Matching and Off-Design Analysis
11.1 Introduction
11.2 Engine (Steady-State) Component Matching
11.3 Engine Off-Design Analysis
11.4 Unchocked Nozzles and Other Off-Design Iteration Strategies
11.5 Principles of Engine Performance Testing
11.6 Summary
References
Problems
12. Chemical Rocket and Hypersonic Propulsion
12.1 Introduction
12.2 From Takeoff to Earth Orbit
12.3 Chemical Rockets
12.4 Chemical Rocket Applications
12.5 New Parameters in Rocket Propulsion
12.6 Thrust Coefficient, CF
12.7 Characteristic Velocity, c*
12.8 Flight Performance
12.9 Multistage Rockets
12.10 Propulsive and Overall Efficiencies
12.11 Chemical Rocket Combustion Chamber
12.12 Thrust Chamber Cooling
12.13 Combustor Volume and Shape
12.14 Rocket Nozzles
12.15 High-Speed Airbreathing Engines
12.16 Rocket-Based Airbreathing Propulsion
12.17 Summary
References
Problems
Appendices
A. U.S. Standard Atmosphere 905
B. Isentropic Table 909
C. Normal Shock Table 927
D. Rayleigh Flow 941
E. Fanno Flow 951
F. PrandtlâMeyer Function and Mach Angle 961
G. Oblique Shock Charts 965
H. Conical Shock Charts 971
I. Cascade Data 975
J. Web Sites 981
K. 10-Minute Quizzes 983
L. Some âRules of Thumbâ and Trends in Aircraft Propulsion 1001
Index
zyText are leading print textbooks available in full on the zyBooks platform. Each zyText has been adapted to include learning questions and answer-specific feedback allowing for a quick and easy transition to an engaging digital experience for instructors and students.
What Youâll Find in this zyText
- Incorporates the complete text
- Over 150 learning questions with answer-specific feedback
- Customization tools letting you add, remove or reorder chapters and sections
- Options to align the book directly to your syllabus â including videos, images, text
- Analytics that help you measure student engagement
- Ability to hold students accountable for reading before class
- A competitive low price point
- Students can keep a PDF version of key chapters at no additional cost
A leading resource on sustainable aviation, alternative jet fuels, and new propulsion systems
Â
This book tackles the impact of aviation on the environment at the engine component level, as well as the role of propulsion system integration on fuel burn. It also discusses combustion emissions, including greenhouse gases, carbon monoxide, unburned hydrocarbons (UHC), and oxides of nitrogen (NOx). Alternative jet fuels, like second generation biofuels and hydrogen, are also presented as well as aviation noise from airframe to engine and its impact on community noise in landing and takeoff cycles;Â promising new technologies for propulsion and power, like the ultra-high bypass (UHB) turbofan and hybrid-electric and electric propulsion systems.
Authors
Saeed Farokhi
